Folding and Sealing Machine
A carton folding and sealing machine with belt drive on both sides. It automatically folds the top flaps and seals the top and bottom simultaneously with one tape operation. Operators can manually adjust the height and width for different carton sizes. The machine can run as a standalone unit or connect to a production line.
Share your quantity and application requirements for a quotation.
Folding and Sealing Machine product image
Product quotation
Add this product to your enquiry
Combine your requirements in one quotation request. Confirm quantities and specifications before submitting.
- Model
- EP-F500
- SKU
- EP-F500
Verified technical specifications
| Package size | Minimum 200 × 150 × 150 mm; maximum 600 × 500 × 500 mm |
|---|---|
| Belt speed | 20 m/min |
| Machine size | L1700 mm × W930 mm × H1510 mm |
| Shipping size | L1760 mm × W1040 mm × H1550 mm |
| Power supply | 220 V / 380 V, 50 Hz |
| Power output | 100 W × 2 |
| Air pressure | 6 kgf/cm², 40 NL/min |
| Tape size | Width 48 / 60 / 72 mm |
| Table height | 600-650 mm (adjustable) |
| Weight | 200 kg / 270 kg |
Product overview
Applications
A carton folding and sealing machine with belt drive on both sides. It automatically folds the top flaps and seals the top and bottom simultaneously with one tape operation. Operators can manually adjust the height and width for different carton sizes. The machine can run as a standalone unit or connect to a production line.
Technical Parameters
| Package size | Minimum 200 × 150 × 150 mm; maximum 600 × 500 × 500 mm |
|---|---|
| Belt speed | 20 m/min |
| Machine size | L1700 mm × W930 mm × H1510 mm |
| Shipping size | L1760 mm × W1040 mm × H1550 mm |
| Power supply | 220 V / 380 V, 50 Hz |
| Power output | 100 W × 2 |
| Air pressure | 6 kgf/cm², 40 NL/min |
| Tape size | Width 48 / 60 / 72 mm |
| Table height | 600-650 mm (adjustable) |
| Weight | 200 kg / 270 kg |
